Function Details & Illustrated Description of Forklift Attachments
Note: This document is formatted in standard Word style, classifying various forklift attachments with clear labels of core functions, unique advantages and applicable scenarios. It is equipped with corresponding schematic diagrams to distinguish the differences of each attachment, facilitating model selection, staff training and promotional use.
1. Basic Pallet Handling Attachments (Most Commonly Used for Palletized Goods)
1.1 Standard Forks/Tines
Core Function: As the basic load-bearing component of a forklift, it features an L-shaped structure that inserts into the bottom of pallets to realize lifting, transferring and stacking of goods, serving as the standard attachment for all forklifts.
Unique Advantages: Simple structure, strong load-bearing capacity, compatible with most standard pallets, high universality and no extra debugging required.
Applicable Scenarios: Basic pallet handling operations such as conventional warehousing, logistics loading & unloading, and factory goods transfer.
1.2 Side Shifter
Core Function: Driven by hydraulic pressure, the forks can move horizontally left and right as a whole without moving the forklift body, realizing accurate alignment of goods with an adjustment range of 100-150mm normally.
Unique Advantages: Greatly improves operation efficiency in narrow passages and truck compartments, reduces repeated body movement, and lowers risks of goods collision and forklift scraping.
Applicable Scenarios: Narrow aisle warehouses, container loading & unloading, and fixed-point unloading of trucks.
1.3 Fork Positioner
Core Function: Automatically adjusts the distance between two forks via hydraulic pressure, adapting to pallets and goods of different widths without manual adjustment off the forklift.
Unique Advantages: Compatible with multi-spec pallets, saves manual fork adjustment time, avoids potential safety hazards of manual adjustment, and improves transfer efficiency.
Applicable Scenarios: Multi-category goods warehousing, logistics sorting centers, and scenarios requiring frequent pallet specification changes.
1.4 Single-Double Pallet Handler
Core Function: Supports flexible mode switching, capable of handling single pallets or hydraulically expanding to carry two side-by-side pallets simultaneously without exceeding the standard width of the forklift.
Unique Advantages: Doubles transfer efficiency, occupies no extra aisle space, and is suitable for large-volume goods turnover.
Applicable Scenarios: Large warehousing centers, e-commerce warehouses, and large-volume transfer of food and beverages.
2. Clamp Attachments (Non-Pallet Handling for Special/Soft Goods)
2.1 Bale Clamp
Core Function: Adopts flexible clamp arms to hydraulically grip non-pallet soft goods, with adjustable pressure to avoid damage to goods.
Unique Advantages: Replaces pallets to save costs, adapts to fluffy soft goods, and grips stably without scattering.
Applicable Scenarios: Handling of soft bale goods such as cotton, wool, waste paper, hay and sponge.
2.2 Carton Clamp
Core Function: Features large-area flat clamp arms to grip boxed goods, with anti-slip protection on the clamp surface to prevent indentations and damages.
Unique Advantages: Enables non-pallet handling for regular boxed goods, protects outer packaging, and is suitable for high value-added boxed products.
Applicable Scenarios: Transfer of boxed goods such as home appliances, e-commerce cartons, daily chemicals and food.
2.3 Paper Roll Clamp
Core Function: Equipped with arc-fit clamp arms and 360° rotation function, grips paper rolls, film rolls and other coiled goods to prevent rolling and crushing.
Unique Advantages: Exclusive arc design fits coiled goods perfectly, rotation function facilitates goods placement and unloading, and eliminates coiled material damage.
Applicable Scenarios: Transfer of paper rolls and film rolls in paper mills, printing plants and ports.
2.4 Drum Clamp
Core Function: Features special buckle/hoop structure to stably grip oil drums, chemical drums and plastic drums, and can realize material pouring with tilting function.
Unique Advantages: Prevents leakage and rolling, adapts to single/multi-drum handling, and integrates transfer and unloading functions.
Applicable Scenarios: Handling and pouring of various drum materials in chemical, food and coating industries.
3. Push, Rotate & Tilt Attachments (For Special Unloading & Turning Operations)
3.1 Push-Pull
Core Function: Works with slip sheets to realize non-pallet push-pull handling, pushing or pulling goods off slip sheets to replace traditional pallets.
Unique Advantages: Saves pallet procurement and maintenance costs, improves warehouse storage capacity, and adapts to regular full-pallet goods.
Applicable Scenarios: Non-pallet transfer of full-pallet bagged/boxed goods such as beverages, daily chemicals and grains.
3.2 360° Rotator
Core Function: Drives forks/clamps to rotate 360° in all directions, realizing goods turning, material pouring and posture adjustment.
Unique Advantages: Flexible rotation, supports forward/reverse turning, and adapts to various operations requiring unloading and turning.
Applicable Scenarios: Waste dumping, food raw material pouring, workpiece turning and bin emptying.
3.3 Tilting Bucket
Core Function: Replaces forks with a bucket structure to shovel bulk materials, and realizes automatic unloading via hydraulic tilting.
Unique Advantages: Integrates shoveling and tilting unloading, adapts to bulk materials without manual loading & unloading.
Applicable Scenarios: Transfer of bulk materials such as sand, gravel, grains, industrial waste and construction waste.
4. Lifting & Special Operation Attachments (Expanding Forklift Operation Scenarios)
4.1 Lifting Jib
Core Function: Equipped with a lifting arm structure to convert the forklift into a simple crane, lifting irregular, ultra-long and heavy goods with a hook.
Unique Advantages: Expands the lifting function of forklifts, makes up for the shortage that forks cannot handle special-shaped goods, and eliminates the need for additional cranes.
Applicable Scenarios: Factory equipment relocation, steel pipe/section lifting, and heavy goods transfer on construction sites.
4.2 Fork Extension
Core Function: Directly sleeved on standard forks to extend fork length, adapting to ultra-long goods handling.
Unique Advantages: Convenient installation, low cost, suitable for temporary ultra-long goods transfer without customized long forks.
Applicable Scenarios: Temporary handling of ultra-long goods such as wooden boards, profiles and steel pipes.
Selection Tips: The functional differences of various forklift attachments mainly focus on goods form, handling mode and operation scenarios. Choose basic attachments for palletized goods, clamp attachments for non-pallet special-shaped goods, rotate & tilt attachments for bulk materials/unloading, and lifting jib for hoisting. The selection must match the forklift's rated load and hydraulic interface to ensure operation safety.
