CPC/CPCD
NIULI
Parameter Category | Parameter Item | Unit | CPC35 (Mechanical Transmission) | CPCD35 (Hydraulic Transmission) | Remarks |
|---|---|---|---|---|---|
Basic Parameters | Rated Lifting Capacity | kg | 3500 | 3500 | Load center distance 500mm |
Load Center Distance | mm | 500 | 500 | Standard configuration | |
Standard Lifting Height | mm | 3000 | 3000 | Higher height available on customization | |
Mast Tilt Angle (Forward/Backward) | ° | 6/12 | 6/12 | Standard mast parameters | |
Overall Weight | kg | ≈4700 | ≈4800 | Reference value | |
Minimum Turning Radius | mm | 2640 | 2640 | Reference value | |
Power System | Engine Model | — | Xinchang 490BPG | Xinchang 490BPG | Diesel engine |
Rated Power | kW | 37 | 37 | Rotational speed 2650r.p.m | |
Displacement | L | 2.54 | 2.54 | — | |
Fuel Tank Capacity | L | 70 | 70 | Diesel fuel | |
Performance Parameters | Travel Speed (Loaded/Unloaded) | km/h | 18/19 | 18/19 | — |
Lifting Speed (Loaded/Unloaded) | mm/s | 460/540 | 460/540 | — | |
Lowering Speed (Loaded/Unloaded) | mm/s | 450/420 | 450/420 | — | |
Maximum Climbing Capacity | % | 20 | 20 | Loaded condition | |
Dimension Parameters | Overall Length (Excluding Forks) | mm | 2700 | 2700 | — |
Overall Width | mm | 1225 | 1225 | — | |
Roof Guard Height | mm | 2090 | 2090 | — | |
Minimum Ground Clearance | mm | 120 | 120 | — | |
Mast Height (Unlifted) | mm | 2125 | 2125 | — |
The above parameters are official standard configuration data of Niuli Machinery. Actual parameters may vary slightly due to customized configurations (such as customized lifting height, special tires, etc.).
Compared with the mechanical transmission (CPC35), the hydraulic transmission (CPCD35) has smoother operation, which is suitable for working conditions with frequent start-stop and large load changes.
The forklift is equipped with a high-strength roof guard and an engine automatic monitoring system (some models). The system will automatically shut down the engine when the engine oil pressure is too low or the water temperature is too high to ensure operation safety.
It is recommended to use the forklift in accordance with the operating manual and conduct regular maintenance to ensure its stable performance and service life.
Model | Operation Difficulty | Core Features | Applicable Scenarios |
|---|---|---|---|
Electric Forklift (Including Lithium-ion) | Low (Easy to Learn) | Stepless speed change, no clutch; only acceleration and direction need to be controlled, with flexible steering and quick response | Indoor warehousing, narrow aisles, high-frequency start-stop operations |
Automatic-transmission Internal Combustion Forklift | Medium | No frequent gear shifting required; general coordination between hands and feet is sufficient, with stable power output | Outdoor general-purpose use, light-to-medium load handling |
Manual-transmission Internal Combustion Forklift | Medium to High | Requires coordination of clutch, accelerator and hydraulic systems; heavy-load or slope operations test operational skills more | Large-tonnage tasks, complex working conditions, outdoor operations |
Basic Operations (starting, lifting, turning): Can be mastered after formal training and 1–3 days of hands-on practice; on-the-job operation is allowed with a valid certificate.
High-difficulty Scenarios (meeting in narrow aisles, stacking in high shelves, loading/unloading on slopes, container stuffing): Require experience accumulation, precise control and risk prediction.
Mechanical Protection: Overhead guard (FOPS), three-point seat belt and non-slip seat prevent operators from being thrown out or crushed in case of rollover.
Electronic Protection: Lateral stabilizers and tilt sensors detect abnormal body tilt angles and trigger audible-visual alarms; some models limit steering or power output to avoid rollover.
Operation Assistance: Speed limiter (≤8km/h in turns/narrow aisles) and mast backward-tilting design reduce the risk of center-of-gravity shift.
Real-time Monitoring: Pressure sensors on forks/masts collect weight data, and dynamically calculate safety thresholds in combination with mast angle and fork height.
Graded Protection: Level 1 warning (10% overload) triggers buzzer prompts; Level 2 (20% overload) activates audible-visual alarms plus speed limitation; Level 3 (30% overload) locks mast lifting and forces unloading.
Interlocked Control: Integrated with hydraulic and power systems, it restricts lifting or traveling when overloaded, eliminating rollover risks from the source.
Collision Warning: Ultrasonic/millimeter-wave radar detects obstacles 360° around the vehicle, triggering audible-visual alarms or interlocked braking.
Emergency Devices: One-button power-off, lowering and flameout for quick shutdown in emergency situations.
Vision Assistance: Boundary lights, U-shaped lights and reversing buzzers reduce blind spot risks.
For beginners or indoor use, prioritize electric forklifts for their ease of operation and safety; for outdoor or heavy-load use, automatic-transmission internal combustion forklifts are optional.
When purchasing, confirm that anti-rollover and overload alarm systems are standard configurations; prioritize models with dynamic load calculation and intelligent restriction functions.
Operational Specifications: Strictly comply with the rated load, keep forks 5–10cm above the ground during travel, decelerate and sound the horn when turning, and avoid sudden braking or sharp turns.
