CPD“K Series”/ “F Series”

Name: CPD“K Series”/ “F Series”
Brand: NIULI
Rating: 5.0 (48 reviews)

Electric Forklift
Capacity: 3000kg/3500kg

Max. lifting height: 6000mm
This lithium-ion forklift is designed based on diesel forklifts and continues the design appearance of diesel forklifts, with excellent performance similar to diesel forklifts

Availability:



Inquire Add to Basket

Model:
CPD Electric K35 Series
Brand:
NIULI

Product Description

Category	Parameter Item	Unit	CPD-K30	CPD-K35	CPD-F30	CPD-F35
Overview	1.1 Manufacturer	-	NIULI	NIULI	NIULI	NIULI
	1.2 Model	-	CPD-K30	CPD-K35	CPD-F30	CPD-F35
	1.3 Power Type	-	Electric	Electric	Electric	Electric
	1.4 Operation Type	-	Seat	Seat	Seat	Seat
	1.5 Rated capacity (Q)	kg	3000	3500	3000	3500
	1.6 Load overhang (c)	mm	-	500	-	-
	1.7 Front centre (x)	mm	468	-	500	-
	1.8 Wheelbase (y)	mm	1800	-	1650	-
Weight	2.1 Self weight	kg	4320	4620	4850	5050
	2.2 Axle Load (Front/Rear/Full load)	kg	6840/7394	-	7770/2880	-
	2.3 Axle Load (Front/Rear/Empty load)	kg	1760/2360	-	1940/2700	-
Tire & Chassis	3.1 Tire Type	-	-	Solid	-	-
	3.2 Front	-	650-10	28×9-15	650-10	-
	3.3 Rear	-	-	2×2	-	-
	3.4 Number of tires (x = drive wheel)	-	-	1000	-	-
	3.5 Front-wheel tread (b3)	mm	984	-	970	-
	3.6 Rear-wheel tread (b4)	mm	6/12	-	6°/6°	-
Dimensions	4.1 Mast Tilt Angle (Front/Rear, α/β)	Grad	2105	-	2655	-
	4.2 Mast closed height (h1)	mm	-	-	-	-
	4.3 Free lift height (h2)	mm	-	125	-	-
	4.4 Standard lift height (h3)	mm	-	3000	-	-
	4.5 Mast extended height (with Lifting frame, H4)	mm	4265	-	4165	-
	4.6 Overhead Guard Height (H5)	mm	2140	-	2080	-
	4.7 Total Length (With Forks, L1)	mm	3800	3980	2680	3950
	4.8 Total Length (Without Forks, L2)	mm	2681	2760	2760	2800
	4.9 Total Width (B1)	mm	1245	-	1220	-
	4.10 Fork Size (L×W×T, s×e×L)	mm	1070×125×4	1070×125×5	1220×125×50	-
	4.11 Fork Rack Width Standard (W)	mm	-	ISO3A	-	-
	4.12 Fork Rack Width (W)	mm	1100	-	1150	-
	4.13 Fork Spacing (m1)	mm	250/1000	-	250/1150	-
	4.14 Min. ground clearance (Lifting frame, m2)	mm	120	-	110	-
	4.15 Min. ground clearance (Truck Body, n2)	mm	125	-	140	-
	4.16 Aisle width for pallets (1000×1200, Transversal; 800×1200, Longitudinal, A2)	mm	4280	4335	2360	2360
	4.17 Aisle width for pallets (Ast)	mm	2540	2610	4295	4295
	4.18 Min. turning radius (Wa)	mm	2650	2780	2400	2400
Parameters	5.1 Max. travel speed (No load/Full load)	km/h	18/15	-	15/18	-
	5.2 Max. lifting speed (Full load/No load)	mm/s	280/390	-	550/430	-
	5.3 Descending speed (No load/Full load)	mm/s	-	≤600	-	-
	5.4 Traction power (laden/unladen)	KW	-	21	-	-
	5.5 Gradability (laden/unladen)	%	18/15	-	22/25	-
	5.6 Driving brake	-	-	Mechanical hydraulic	-	-
	5.7 Parking brake	-	-	Mechanical	-	-
Electrical	6.1 Traction motor power (S2 60min work system)	kW	17	-	-	21
	6.2 Lifting motor power (S3 15% work system)	kW	13	-	-	16
	6.3 Specification of battery (Voltage/Capacity)	V/Ah	80V/200Ah	-	80V/460Ah	-
Other	7.1 Driving control system	-	-	MOSFET/AC	-	-
	7.2 Controller brand	-	MEGMEET	-	SME	-
	7.4 Noise	dB	-	74	-	-
	7.5 Traction pin diameter	-	∅25	-	25	-
	7.6 Hydraulic oil tank capacity	liter	-	50	-	-

Core Advantages of Electric Forklifts

Combined with the technical characteristics and industrial application scenarios of electric forklifts, their core advantages can be summarized into four dimensions: "Environmental Friendliness, Economy, Efficiency, and Safety". They are especially suitable for the upgrading needs of modern warehousing and logistics, manufacturing, e-commerce and other industries. Below is a detailed breakdown (directly applicable for product introductions, customer communications, or marketing materials):

I. Core Advantage 1: Environmental Friendliness – Aligning with Policies and Scenario Requirements

Zero Emissions + Low Noise for Green Compliance
Powered by batteries, electric forklifts produce no exhaust emissions (such as CO and NOx pollutants), perfectly complying with global "carbon neutrality" policies and indoor operation requirements (e.g., warehouses, food factories, pharmaceutical workshops, electronic plants). They eliminate environmental pollution and health risks for workers. With an operating noise ≤75dB (far lower than the 90dB+ of internal combustion forklifts), they create a quiet and comfortable working environment, reducing employee noise fatigue.
Odor-Free + Clean Operation to Protect Goods and Sites
Free of fuel leakage, engine oil odors, and other issues, they are particularly suitable for transporting goods with high cleanliness requirements (e.g., precision equipment, food, and pharmaceuticals). They also prevent oil contamination of the site, reducing site cleaning costs.

II. Core Advantage 2: Economic Efficiency – Lower Long-Term Operating Costs

Low Energy Consumption, Saving 50%+ Expenses
Electricity costs are only 1/3 to 1/2 of fuel costs. For example, a 10-ton electric forklift consumes approximately 15-20 kWh per hour, with a cost ≤15 RMB; an internal combustion forklift consumes 5-8 liters of fuel per hour, with a cost ≥40 RMB. Long-term use can significantly reduce operating costs.
Simple Maintenance and Low Failure Rate
Electric forklifts have a streamlined structure (no complex components such as engines, gearboxes, or clutches). Maintenance only requires regular inspections of batteries, motors, and hydraulic systems. The maintenance frequency is 30% lower than that of internal combustion forklifts, with fewer parts wear and lower repair costs (annual maintenance costs are about 1/2 of internal combustion forklifts), reducing downtime.
Long Battery Life and High Residual Value
High-quality lithium batteries (such as the lithium iron phosphate batteries adapted for Niuli electric forklifts) have a cycle life ≥2000 times and can be used normally for 5-8 years. Additionally, batteries are recyclable, and the overall residual value of the vehicle is 20%-30% higher than that of internal combustion forklifts.

III. Core Advantage 3: High Efficiency – Adapting to High-Intensity Working Conditions

Stable Power Output and High Operational Efficiency
Motors deliver high instant torque, ensuring smooth acceleration and fast startup without the shift shock of internal combustion forklifts. They are especially suitable for frequent starts/stops and short-distance transportation (e.g., warehouse loading/unloading, shelf access). With a driving speed of ≤12km/h (no-load) and ≤10km/h (loaded), and a lifting speed of ≥0.5m/s, they are comparable to internal combustion forklifts, improving hourly workload.
Sufficient Battery Life for Multi-Scenario Needs
Mainstream electric forklifts have a cruising range of 6-12 hours (depending on battery capacity and working conditions), supporting fast charging (80% charge in 1-2 hours) or battery swapping (3-minute quick swap) to meet 8-hour high-intensity daily operations. Some models (e.g., Niuli Electric Counterbalanced Forklifts) can be equipped with dual battery packs for 24/7 continuous operation, adapting to peak logistics demands.
Intelligent Configuration to Improve Management Efficiency
Equipped with intelligent systems such as GPS positioning, power monitoring, fault alarms, and operation statistics (e.g., Niuli Forklift's intelligent management platform), enterprises can real-time monitor vehicle location, energy consumption, and workload, optimize scheduling plans, and reduce management costs.

IV. Core Advantage 4: Safety and Reliability – Reducing Operational Risks

Simple Operation with Low Threshold
Electric forklifts use throttle, steering wheel, and joystick controls, eliminating the need for clutch shifting, allowing new operators to master quickly. Equipped with electric power steering, steering is effortless, reducing driver labor intensity and operational errors.
Comprehensive Safety Configuration and Upgraded Protection
Standard configurations include anti-rollover systems, emergency power-off switches, hydraulic locking devices, audio-visual alarms, and reverse cameras. The low-center-of-gravity design (rational battery layout) enhances driving stability, making them especially suitable for narrow-aisle and high-shelf operations (e.g., Niuli Electric Reach Forklifts with a minimum turning radius ≤1.5m), reducing collision risks.
No High-Temperature Risks for Safer Operation
Without high-temperature engine components, they avoid fire risks caused by fuel leakage, making them suitable for high-temperature environments or flammable and explosive locations (e.g., chemical warehouses) when equipped with explosion-proof models.

V. Applicable Scenarios: Fields Where Electric Forklifts Excel

Indoor operations: Warehouses, workshops, supermarket logistics centers, cold chain storage
High environmental requirements: Food/pharmaceutical/electronic industries, park-based enterprises
High-frequency short-distance transportation: Loading/unloading, shelf access, workshop transfer
Cost-sensitive: Small and medium-sized enterprises, long-term operation scenarios

Summary (Directly Applicable for Oral Presentations or Slogans)

The core advantages of electric forklifts lie in "taking environmental compliance as the foundation, low-cost operation as the core, and high efficiency and safety as the guarantee". They not only meet policy requirements but also help enterprises reduce long-term costs and improve operational efficiency, making them the "preferred equipment" for modern logistics upgrading. Building on these advantages, Niuli Electric Forklifts further optimize battery life, load capacity (covering 1-10 tons), and intelligent configurations to adapt to more segmented scenario needs, empowering enterprises to achieve "cost reduction, efficiency improvement, and green development".
