CPCD70
NIULI
8427900000
| General | 1 | Model | CPCD70 | ||||
| 2 | Power Type | Diesel | |||||
| 3 | Rated Capacity | kg | 7000 | ||||
| 4 | Load center | mm | 600 | ||||
| Characteristic*Dimension | 5 | Lift Height | mm | 3000 | |||
| 6 | Fork Size | L*W*T | mm | 1220*250*55 | |||
| 7 | Mast Tilt Angle | F/R | Deng | 6°/12° | |||
| 8 | Front Overhang(wheel center to fork face) | mm | 595 | ||||
| 9 | Ground Clearance(Bottom of mast) | mm | 200 | ||||
| 10 | Overall Dimension | Length of fork (with/without fork) | mm | 3560 | |||
| 11 | Overall width | mm | 2010 | ||||
| 12 | Mast lowered height | mm | 2500 | ||||
| 13 | Mast extended height (with backrest) | mm | 4380 | ||||
| 14 | Overhead guard height | mm | 2470 | ||||
| 15 | Truning radius(outside) | mm | 3350 | ||||
| 16 | Min. intersecting aisle | mm | 3040 | ||||
| Performance | 17 | speed | Travel(full load) | km/h | 26 | ||
| 18 | Lifting(full load) | mm/s | 460 | ||||
| 19 | Max. gradeability | % | 20 | ||||
| Chassis | 20 | Tire | Front | 8.25-15-14PR | |||
| 21 | Rear | 8.25-15-14PR | |||||
| 22 | Wheelbase | mm | 2250 | ||||
| 23 | Self weight | kg | 9750 | ||||
| Power&Transmission | 24 | Battery | Voltage/Capacity | V/Ah | 12V/80Ah)*2 | ||
| 25 | Engine | Model | CY6102BG | ISUZU 6BG1 | |||
| 26 | Manufacturer | ChaoChai | ISUZU | ||||
| 27 | Rated output/r.p.m. | Kw/r.p.m | 81/2500 | 82/2000 | |||
| 28 | Rated torque/r.p.m | Nm/r.p.m | 353/1650 | 415/1600 | |||
| 29 | No. of cylinder | 6 | 6 | ||||
| 30 | Bore*stroke | mm | 102*118 | 105*125 | |||
| 31 | Displacement | cc | 5795 | 6494 | |||
| 32 | Fuel tank capacity | L | 110 | 1400 | |||
| 33 | Transmission | Type | Hydrauic | ||||
| 34 | Stage | FWD*RVS | 2\2 | ||||
| 35 | Operating pressure for attachment | Mpa | 19 | ||||
