CTQR
NIULI
8427900000
• The CTQR is equipped with a pure electric steering, which provides high operating comfort, reduces the fatigue strength of the operation, and improves the work efficiency
• With intelligent instrument panel, ergonomic design, multi-function intelligent instrument and wheel display function, the operation is more comfortable and convenient
• Gantry with high redundant capacity, high-precision gantry, no load loss below 7150mm, and the load capacity is also excellent at super high level
• The seat is adjustable, front and rear adjustable, which can provide the most comfortable operating environment for the operator and reduce fatigue
• The three-point support structure design of the car body makes the operation of the stacker more stable and flexible
Parameters | Model |
| CTQR |
Brand |
| NIULI | |
Opreate type |
| Seated | |
Rated capacity | KG | 2000 | |
Load center | mm | 500 | |
Drive unit |
| Electric | |
Wheelbase | mm | 1525 | |
Self weight(with battery) | Kg | 4000 | |
Wheels & Tyres | Driving wheel | mm | 350*120 |
Load wheel | mm | 300*120 | |
Balance wheel | mm | / | |
Driving wheel wheelbase | mm | / | |
Load wheel wheelbase | mm | 1170 | |
Dimensions | Max. lift height | mm | 7500 |
Max. working height | mm | 8470 | |
Fork ground clearance | mm | 75 | |
Total width | mm | 1270/1290 | |
Fork dimensions | mm | L/W/H=1070*122*40 | |
Turning radius | mm | 1798 | |
Performance | Traction speed(load/unload) | Km/h | 8.5/10 |
Lifting speed(load/ unload) | mm/s | 210/340 | |
Lowering speed(load/unload) | mm/s | 300/250 | |
Max. grade ability(load/unolad) | % | 10 | |
Brake type |
| Mechanical | |
Motors & Battery | Traction motor | Kw | 5.5 |
Lift motor | Kw | 8.6 | |
Battery volts/ampere | V/Ah | 48/560 | |
Battery weight | Kg | 920 |
