CPCD30
NIULI
8427900000
| General | 1 | Model | CPC30 | CPCD30 | |||||
| 2 | Power Type | Diesel | Diesel | ||||||
| 3 | Rated Capacity | kg | 3000 | 3000 | |||||
| 4 | Load center | mm | 500 | 500 | |||||
| Characteristic*Dimension | 5 | Lift Height | mm | 3000 | 3000 | ||||
| 6 | Fork Size | L*W*T | mm | 1070*125*45 | 1070*125*45 | ||||
| 7 | Mast Tilt Angle | F/R | Deng | 6°/12° | 6°/12° | ||||
| 8 | Front Overhang(wheel center to fork face) | mm | 500 | 500 | |||||
| 9 | Ground Clearance(Bottom of mast) | mm | 126 | 126 | |||||
| 10 | Overall Dimension | Length of fork (with/without fork) | mm | 3980/2980 | 3980/2980 | ||||
| 11 | Overall width | mm | 1230 | 1230 | |||||
| 12 | Mast lowered height | mm | 2105 | 2105 | |||||
| 13 | Mast extended height (with backrest) | mm | 4110 | 4110 | |||||
| 14 | Overhead guard height | mm | 2140 | 2140 | |||||
| 15 | Truning radius(outside) | mm | 2640 | 2640 | |||||
| 16 | Min. intersecting aisle | mm | 2700 | 2700 | |||||
| Performance | 17 | speed | Travel(full/empty load) | km/h | 18/19 | 18/19 | |||
| 18 | Lifting(full/empty load) | mm/s | 360/440 | 360/440 | |||||
| 19 | Max. gradeability | % | 20 | 20 | |||||
| Chassis | 20 | Tire | Front | 28*9-15-12PR | 28*9-15-12PR | ||||
| 21 | Rear | 6.50-10-10PR | 6.50-10-10PR | ||||||
| 22 | Wheelbase | mm | 1850 | 1850 | |||||
| 23 | Self weight | kg | 4500 | 4500 | |||||
| Power&Transmission | 24 | Battery | Voltage/Capacity | V/Ah | 12/120 | 12/120 | |||
| 25 | Engine | Model | JE493G | 4JG2 | JE493G | 4JG2 | |||
| 26 | Manufacturer | ISUZU | ISUZU | ISUZU | ISUZU | ||||
| 27 | Rated output/r.p.m. | Kw/r.p.m | 36/2500 | 44/2450 | 36/2500 | 44/2450 | |||
| 28 | Rated torque/r.p.m | Nm/r.p.m | 160/1800-2000 | 186/1600-1800 | 160/1800-2000 | 186/1600-1800 | |||
| 29 | No. of cylinder | 4 | 4 | 4 | 4 | ||||
| 30 | Bore*stroke | mm | 93*102 | 95.4*107 | 93*102 | 95.4*107 | |||
| 31 | Displacement | cc | 2771 | 3059 | 2771 | 3059 | |||
| 32 | Fuel tank capacity | L | 60 | 60 | 60 | 60 | |||
| 33 | Transmission | Type | Machanical | Hydrauic | |||||
| 34 | Stage | FWD*RVS | 1/1(2/2)/1/1 | 1/1(2/2)/1/1 | |||||
| 35 | Operating pressure for attachment | Mpa | 17.5 | 17.5 | |||||
